FR4000 Robotic Mower FAQs
Welcome to the FR4000 Robotic Mower FAQs, where you’ll find quick answers to common questions. This page covers infrastructure needs, hardware details, software functions, and use cases—helping you set up and enjoy your FR4000 with ease.
Robot Lawn Mower Infrastructure Related FAQs
Here are some common questions about FJDynamic FR4000 Robotic Mower.
No. It uses a GNSS-based virtual boundary system, so there’s no need to install physical wires.
Yes. To ensure optimal performance, please follow these guidelines:
• Choose an open area with a clear view of the sky.
• Install the base station at a high location whenever possible.
• Avoid any obstructions between the base station and the mower.
• Mount it on a stable structure that won’t shift or move.
• Ensure the location allows for power supply.
At least 1 kilometer.
• Rain may slightly affect the positioning accuracy of the base station and the mower, but the impact is minimal.
• All components are rain-resistant. The mower is rated IPX5, the base station IP67, and the charging station IP65.
The base station can be moved. However, after relocating it, all previously marked charging station locations and mapped boundaries in the software will change, requiring a complete reset. Therefore, it is recommended to deploy it correctly the first time to avoid moving.
No, currently only FJD products are supported.
Yes, for details about solar power systems, please consult your sales manager.
Yes, first you need an active Ntrip account. Input the account into the FJDLandscaping app to enable network base station positioning.
Yes, but relocation changes the path from the charging station to the work area, requiring remapping.
(1) Installed on flat ground.
(2) ≥2m obstacle-free space in front; ≥1.5m on both sides.
(3) Grass height under station ≤5cm (≈2 inches).
(4) Open sky view (no obstructions).
(5) Access to wired power supply.
(6) Clear path from station to work area.
Clarification:
(1) Recommended but not mandatory.
(2) Without base station, use Ntrip + Cors network for positioning.
(3) Without charging station, "stationless startup" is supported (no auto-return).
Placement rules:
(1) RTK base station must be outdoors.
(2) Charging station: outdoor recommended; indoor allowed if robot can exit via vision mode. .
Can be deployed inside or outside the mowing area. Minimize distance to reduce idle travel time.
2.5cm diameter.
Robot Lawn Mower Hardware dependent FAQs
2 hours (full charge)
3 hours for standard residential lawns.
Three-speed settings:
•Low: 0.3m/s
•Medium: 0.4m/s
•High: 0.5m/s
Recommended ≤4,000㎡. No hard limit on area size/number of maps.
Tires cannot be replaced, but add-on gears can enhance traction.
Standard: 20-60mm. Can be modified to 10-50mm with structural add-ons.
8-12 weeks (at mid-height setting, mowing 3x/week).
Two sets included.
Sensors:
(1) RTK: Positioning
(2) Binocular cameras: Obstacle detection
(3) Monocular camera: Station/boundary recognition
(4) IMU: Posture monitoring
(5) Bumper sensor: Collision detection
(6) Lift sensor: Tilt/rollover prevention
(7) Rain sensor: Weather detection
Yes, RTK works in darkness.
<60 dB during operation.
Three blade speeds:
•Low: 1,280 RPM
•Medium: 2,240 RPM
•High: 3,200 RPM
Metal plate functions:
(1) Flattens tall grass for efficient cutting.
(2) Protects underside on rough terrain.
(3) Shields blades for safety.
Removable if Terrain is flat, grass is short, and user fully understands risks.
Required for remote management (charging station/FR4000/base station).
Vision sensors detour around dense shrubs.
Robot Lawn Mower Software Dependent FAQs
Mapping methods:
(1) Manual FR4000 operation to outline area.
(2) Boundary markers + platform import.
Not supported for direct map selection in app.
Enabled after signing liability waiver.
Exclusion methods:
(1) Manual FR4000 operation to mark no-go zones.
(2) Boundary markers + platform import.
Yes, resume function supported.
Enabled after signing liability waiver.
Software:
•Residential: FJD Landscaping app only.
•Commercial: + Cloud management platform.
Unlimited connections. Last command takes priority.
Yes, via online remote management platform.
Yes, on app stores.
Compatible with all FJD robotic mowers.
Troubleshooting:
•Bluetooth: Operate within ≤3m.
•Remote control: Ensure stable internet.
All versions work. Updates add features/fixes (latest recommended).
Rate via app store after download.
Adjustable in app during map creation or pre-operation
Robot Mower Use Case Correlation FAQs
Supported lawns:
(1) Residential
(2) Commercial (golf courses, sports fields)
(3) Parks/green spaces
(4) Grass types: Bermuda, fescue, bluegrass, bentgrass, zoysia, ryegrass, etc.
Max grass height: ≤100mm.
Adjustment range: 20-60mm (standard).
Height adjustment: Via app (pre-map, pre-task, or during operation).
(1) When the grass is too tall, it is recommended to first use other equipment to give the lawn a thorough trimming
(2) For the first operation with a small mower, it is suggested that the grass height be within the range of 50–100 mm.
(3) Never cut more than one-third of the plant's height or 25 mm at a time
(4) If a lower cutting height is desired, to prevent excessively long grass clippings that may not be effectively discharged, multiple cutting sessions are recommended
(5) To achieve a neat appearance after mowing, it is best to perform the task in the afternoon or evening when there is less moisture
Actively avoids moving objects via sensors.
Auto-recovery: Reverses path or detours; alerts if stuck.
Operating temp: 0°C to 55°C.
Not recommended (auto-return triggered; poor traction/results).
Not supported (extreme weather monitoring).
Yes, edge trimming enabled if terrain allows vision-based navigation.
Safety measures:
(1) Manual boundary setup to avoid hazards.
(2) Vision sensors provide secondary detection
Weather impact:
(1) Normal operation: Overcast/sunny
(2) Rain: Auto-return
(3) Hail/wind: Operation suspended
(4) Post-storm: Delayed restart for safety
Handles uneven terrain with ≤5cm depressions (caster wheel: 9cm diameter).
Slopes ≤33° supported. Steeper slopes require manual tools.
Yes, vision sensors avoid sprinklers.
Pre-mow tall grass manually/with other tools before FR4000 deployment.
Auto-escape attempts: Reverses/detours; alerts user if failed.
Robot Mower Other Related FAQs
2-year warranty.
Coverage includes:
•RTK base station
•Charging station
•FR4000 battery
•Internal sensors
•Wheel axles
•Mainboard
Excludes wear parts: blades, tires, cosmetic accessorie
Updates:
•Firmware/software: User-initiated via app.
•New hardware: Contact dealer for replacement (paid/free).
Theft alert: App/SMS/email triggered if moved beyond virtual fence.
APP alert if moved outside work area.
APP alert based on tilt sensors if tipped over.
No, blocks satellite signals/sensors.
User-replaceable. Store indoors in winter; replace every 3 years.
Feedback channels:
(1) Local dealer
(2) Official website
(3) App interface
Global use (no restrictions).
Winter storage:
(1) Store devices at room temperature.
(2) Remove battery; charge to 30-60% before storage.
Damaged parts:
•Under warranty: Mail to dealer for replacement.
•Out of warranty: Purchase replacements via dealer.
Clear clippings only if they impede operation.
Garage charging:
(1) Remove battery → Charge via Type-C.
(2) Portable chargers unavailable (operation requires docking station).
APP alert if docked but not charging.
Low-battery protocol: Sends location via app before shutdown.
Refer to Product Manual(Maintenance section).
